Specifications
| ELECTRICAL | |||||
|---|---|---|---|---|---|
| Frequency Band (MHz) | 617-698 | 698-960 | 1695-2700 | 3300-4200 | 4800-6000 |
| Polarization | Linear, Horizontal | ||||
| Typical Gain (dBi) | 4 | 4 | 5 | 6 | 7 |
| Horizontal Beam Width (°) | 360, Omni-Directional | ||||
| Typical Vertical Beam Width (°) | 70 | 68 | 50 | 60 | 30 |
| Impedance (Ω) | 50 | ||||
| VSWR | ≤2.0 | ≤1.5 | |||
| Maximum Power (W) | 50 | ||||
| MECHANICAL | |||||
| Model | 310005† | ||||
| Connector | N Female | ||||
| Cable Length (in / cm) | 12 / 30 | ||||
| Antenna Size Φ (in / mm) | 9.8 / 250 | ||||
| Packing Size (in / mm) | 10.4×10.4×3.4 / 265×265×90 | ||||
| Weight (lb / kg) | .8 / .4 | ||||
| Radome Material | ABS | ||||
| Operating Humidity (%) | 5-95 | ||||
| Operating Temperature (°F / °C) | -40 - 140 / -40 - 60 | ||||
