The Zinwave Unititvity 5000 Public Safety Remote Unit converts signals from optical to RF and vice versa. It links to the Primary or Secondary Hub via fiber and is typically installed above ceiling tiles or in inconspicuous locations. The two N-Female ports enable the connection of two antennas, one for uplink and one for downlink.
Boasting up to 23 dBm output power, a single Public Safety RV delivers expectational coverage. Wideband, it’s compatible with all Public Safety and LTE bands ranging from 150 MHz to 2700 MHz.
Hardware is NEMA4 compliant. With the Public Safety Splice Tray (sold separately), it can also be IP66 rated. The tray is equipped with three cable entry points, offering flexibility for a variety of fiber, power, and alarm configurations. NFPA-compliant alarming connections are included with the unit.
| Unit Specifications | |
| POWER CONNECTIVITY | 48 V DC POWER INPUT VIA PHOENIX 5.08 mm 2-WAY CONNECTOR; AWG 12-24 |
| FIBER CONNECTIVITY | SC/APC DUPLEX |
| ANTENNA CONNECTIVITY | SIMPLEX N-FEMALE CONNECTORS (TX AND RX) |
| TRAY CONNECTIVITY | 3 GLANDS WITH M16, M32, M20 SCREW THREADS (LEFT TO RIGHT FROM FRONT), BLANK PLATES/GLANDS PROVIDED, CABLE DIAMETERS RANGING BETWEEN 2 mm AND 21 mm CAN BE SUPPORTED WITH SUPPLIED GLANDS |
| OTHER CONNECTIVITY | ALARM RELAY: PHOENIX 5.08 mm 3-WAY WITH NORMALLY CLOSED AND NORMALLY OPEN CONNECTIONS |
| DIMENSIONS W / D / H (mm) | 8.1" (206) x 16.3" (415) x 2.2" (55) MEASUREMENTS INCLUDE SUPPLIED MOUNTING BRACKET AND IP66 ENCLOSURE |
| WEIGHT | 6.6 LBS (3 Kg) |
| ELECTRICAL DEPENDING ON CONFIGURATION | 48 V DC / 0.5 A / 24 W (82 BTU/HR) MINIMUM INPUT VOLTAGE IS 37 V |
| OPERATING TEMP AMBIENT NON-CONDENSING | -5 TO +50 °C (23 TO 122 °F) |
| Approvals & Listings | |
| EUROPE | CE MARKED FOR RADIO EQUIPMENT DIRECTIVE 2014/53/EU AND ROHS DIRECTIVES 2011/65/EC |
| USA FCC | FCC CERTIFIED |
| CANADA | INDUSTRY CANADA CERTIFIED |
| SAFETY | IEC 60950-1; EN 60950-1; UL60950-1, UL LISTED-E486578 |
| LASER SAFETY | IEC 60825-1:2007 |
| UPC | 810005964463 |
